We are Authorized Distributor for Rechner Sensors
We are Rechner Sensor authorized distributor for India. Rechner is well know brand from USA. We supply Rechner products in India for more than decade.
- sales@rendertechindia.com
- +91-8698009335
Rechner product range is complemented by a selection of AtEx approved sensors, ancillary equipment, transistor-based signal amplifiers, control units, and power supplies.
Render is Authorized Distributor for Rechner Sensors
We are Rechner Sensors authorized distributor, it is essential to understand the key products and offerings that set Rechner Sensors apart in the industry.
Rechner Electronics Industries, Inc. was established in 1978 and since its founding, Rechner USA has proudly served the North American market by providing specialized sensors for the most demanding applications. With direct cooperation with Rechner Germany, Rechner USA has provided custom engineered solutions for many companies for more than 40 years. Rechner USA now has ETL certified products being assembled in Sanborn, NY.
Rechner Sensors Product Overview
Rechner Capacitive Sensors
Rechner Sensors will design and manufacture capacitive sensors to suit your precise requirements, even for small quantities. Rechner offer the most innovative sensor technology and unsurpassed quality. Whether level control or position detection, with more than 1500 models and over 50 years of experience, and a host of different dimensions and process connections, Rechner has the right sensor for you. Capacitive sensors from Rechner will ensure more efficiency for your process and factory automation.
Rechner S-801-26/203-IL4-G1/2-PEEK/VAB-Y3-ETW-HP
Capacitive Sensors
Model G 1/2“
For level control of conductive and/or viscous liquids or pastes, for instance oil, water, ketchup or honey.
Ideal for level control in the Food Industry or Pharmaceutical Industry
Housing material: Stainless steel VA No. 1.4305 (AISI 303)
Adjustment of the sensitivity with ETW- Function (EasyTeach by wire)
With flange connector M 12 x 1
Welding sockets and Varivent adapter available for EHEDG conform mounting.
Rechner KAS-80-26/113-P3-G1-PTFE-Y10-ETW-HP
Capacitive Sensors – S26
Series 80 – PNP
Type of construction G 1”
• Housing material: PTFE
• With flange connector M 12 x 1
• Output function (Antivalent / 2 x normally open / 2 x normally closed) selectable with EasyTeach by Wire
• Operating distance adjustable with EasyTeach by Wire
• Optical guidance during the teach process with the aid of a 2-colour LED
Rechner KAS-40-LEAK-D50-PTFE-N, ATEX
Capacitive Sensors
Series Leak – ATEX
Housing Ø 50 mm
• For use in areas with the risk of gas explosion, zone 0
• Leakage control in clean room / Alarm for containers and pipelines.
• Mounting in „drip trays“ of plastic, glass or metal
• Housing material: PTFE
• Semiconductor Industry, Chemical Industry
Rechner KAS-80-39/23-A-D50-PTFE-Z02-MAG-LEAK
Capacitive Sensors
Series Leak
Housing Ø 50 mm
• Leakage control of liquids in clean room / Alarm for containers and pipelines
• Mounting in „drip trays“ of plastic, glass or metal
• Housing material: PTFE
• Semiconductor Industry, Chemical Industry
• Mount and Go
• Autoadjustment Function
Rechner CAPACITIVE SENSORS WITH EXTREME LONG SENSING DISTANCE (KXS)
Rechner KXA-5-1-B-P-A-ET-Z02-Y90
Capacitive evaluation units
Series KXA-eXtreme
Housing 46,6 x 74,5 x 30 mm
• KXA-… for connection to capacitive sensors KXS-…-M18/… to -M32/…
• Adjustable with EasyTeach by Wire / EasyTeach by Magnet (ETM)
Rechner KXA-5-1MINI-B-P-A-ET-Z02-Y90
Evaluation unit with EasyTeach by Wire (ETW) & EasyTeach by Magnet (ETM)
Capacitive evaluation units
Series KXA-eXtreme
Housing 46,6 x 74,5 x 30 mm
• KXA-…-MINI for connection to capacitive sensors KXS-…-M5/… to -M16/…
• Adjustable with EasyTeach by Wire / EasyTeach by Magnet (ETM)
Rechner KXS-250-M16/30-X-M16-PEEK-250C-X02/Y95
Capacitive sensors
Series KXS-eXtreme
Housing M 16 x 1
• Housing material: PEEK
• For connection to capacitive evaluation units KXA-…MINI
• Extreme large sensing distance
• Up to 250° C ambient temperature
Rechner KXS-250-M30/70-X-M30-PTFE-160C-X02/Y95-E
Kapazitive Sensoren
Serie KXS-eXtreme
Bauform M 30 x 1,5
• Gehäusematerial: PTFE
• Zum Anschluss an kapazitive Auswerter KXA-…
• Extrem hoher Schaltabstand
• Bis 160 °C Umgebungstemperatur
Rechner CAPACITIVE LEVEL MEASUREMENT SYSTEMS (KFI / KFS / KFA / KFX)
Rechner KFS-4-1-90-V10/45-Y95-PEEK/VA
Capacitive Filling Level Probe – KFS
1 variable Limit value switching point
• For connection to the capacitive amplifier KFA-4-1-V08-P-AFB-Y90 AF0002
• Housing material: PEEK, Ø 16 mm
PerLevel
250°C / 482°F
Rechner KFI-1-915-858-PTFE/VAC-D16-G1-IL4-ETW-Y10
Capacitive Filling Level Probe – KFI
i-level
for Food
high chemical resistance
Analogue current output 4…20 mA
• Integrated evaluation electronics
• Easy Teach by wire
• Housing material: PTFE, Ø 16 mm
• Connection head and process connection stainless steel VA no. 1.4305 / AISI 303
• Process connection G1”
• With flange connector M 12 x 1 (5-pin Teach function included)
Rechner KFI-1-R-20000-VAC/PTFE/VAC-D13-G1-IL4-ET-Y10
Capacitive Filling Level Probe
Analogue current output 4…20 mA
For dry bulk materials and non-conductive liquids with low dielectric constant (e.g. oil)
• Adjustable with EasyTeach by Wire, EasyTeach by Magnet
• With flange connector M 12 x 1 (5-pin incl. EasyTeach function)
• Level measurement over the entire active zone (M) up to a maximum of 20 m
• Shortenable measuring probe incl. accessories for isolating fixation of the cable electrode
• Optional: housing with temperature barrier for higher product temperatures
• Optional: Process connection in various versions
Rechner KFI-1-500-320-PEEK-D16-TB50-IL4-ETW-Z02
Capacitive Filling Level Probe – KFI
i-level
for food
Analogue current output 4…20 mA
• Integrated evaluation electronics
• Easy Teach by wire
• Housing material: PEEK, Ø 16 mm
RECHNER PART NUMBER
| RECHNER | KAS-80-A13-A-M18-PTFE/VAb-Y5-1-HP | 801981 |
| RECHNER | KAS-80-30-A-M32-PTFE-Y3-1-HP with PA connector | KA1036 |
| RECHNER | KAS-80-A12-IL4/UL0-M12-PTFE | KA1307 |
| RECHNER | KAS-80-26/113-A-G1-PTFE-Y5-1-HP | KA0642 |
| RECHNER | KAS-40-A 13-N-K-PTFE-STEX, ATEX | KA0994 |
| RECHNER | KAS-80-35-A-D30-PPO-Y3-1-NL | KA1033 |
| RECHNER | KAS-80-26-A-K-Tri-PTFE-Y5-StEx, ATEX | KA0829 |
| RECHNER | KAS-90-30-S-D30-PPO-Z02-1 | 901500 |
| RECHNER | IAS-10-18-S-D18-PTFE-Z02-0 | 115480 |
| RECHNER | KAS-80-50-IL4/UL0-D50-PEEK-Y5-CMaG-HP | KA1454 |
| RECHNER | KAS-80-10-A-D11-PTFE/VAb-Z02-1-HP | KA0045 |
| RECHNER | KAS-80-A23-A-M18-PBT-Z02-1-HP | 803400 |
| RECHNER | KAS-80-35-O-M32-PTFE/VAB-Z02-1-E-HP | 822024 |
| RECHNER | KAS-80-34-A-M32-PTFE/V2A-Y5-3G-3D | KA0849 |
| RECHNER | KAS-70-A24-A-M30-PPO-Y3-1-NL | KA0351 |
| RECHNER | AS-80-A14-A-M30-PPO-Z02-1-NL | KA0544 |
| RECHNER | KAS-80-30-A-M32-PTFE/VAc-Y3-1-NL | KA1583 |
| RECHNER | KAS-80-26/113-A-D22-PTFE-100C-Y5-1-HP | KA0694 |
| RECHNER | KAS-80-30-A-D30-PTFE/MS-Y5-1-HP | 814400 |
| RECHNER | ST-Y5-M12-PVC-4×0.34-0-1-Z05 | 193391 |
| RECHNER | KAS-80-M16-S-M16-PEEK-Y7-1-E-HP | KA0269 |
