We are Authorized Distributor for MBS AG Products
We are authorized MBS AG Distributor, Supplier, Dealer. MBS AG is well know brand from Europe. We supply MBS AG products in India for more than decade.
- sales@rendertechindia.com
- +91-8698009335
We are authorized Distributor for MBS AG Products in India, Render offers access to their top-notch product line, including current transformers for industry, current transformers for tariffs, and medium-voltage transformers.
Render is Authorized Distributor for MBS AG Products
As an Authorized Distributor for MBS AG Products in India, Render offers access to their top-notch product line, including current transformers for industry, current transformers for tariffs, and medium-voltage transformers.
MBS AG, a renowned manufacturer of low-voltage transformers and measuring transducers, has been a key player in the industry since its establishment in 1977. With a wide range of products catering to various sectors such as mechanical and plant engineering, regenerative power recovery, and ship-building, MBS AG continues to provide high-quality solutions to its global clientele.
MBS AG Product Overview
Current transformer for low voltages
Production at MBS AG currently includes over 10,000 low-voltage current converters in the 0.5 series with a maximum operating voltage of 0.72 kV or 1.2 kV in the case of the CTB type series.
All products are manufactured in compliance with the defined technical requirements from DIN EN 61869-1/2, VDE 0414-9-1/2 and DIN 42600. The current version of the standards quoted is used.
The main areas of use for our products are mechanical and plant engineering, ship-building, and wind energy.
Thanks to our extensive portfolio of products, as well as personalised advice from our team of specialist engineers and sales consultants, you will find the ideal low-voltage current transformer for whatever application you are planning.
X Type - Current transformer for harmonics measurements up to 20 kHz
For measurements up to 20 kHz, MBS AG offers the entire XCTB current transformer series that guarantees not only highly accurate transmission up to 20 kHz, but is also thermally designed for use on networks exposed to harmonics. The output signals, as is usual on inductive current transformers compliant with IEC 61869-2, are 1 or 5 A. The output specifications also correspond to the usual values. The transformer can therefore also be used in conventional 50 Hz applications. An additional rating plate defines the frequency transmission behaviour.
Optionally, the supply of primary conductor bars (electrolytic copper, nickel-plated) corresponding to the bar window, including screws DIN 933, complete with nuts, washers and lock washers for mounting in busbars or similar is possible.
VTLS/D - Voltage transformer for low voltage
The low-voltage voltage transformers from MBS AG are especially voltage-resistant and highly efficient thanks to their physical structure. They also offer class-accurate harmonics transmission up to 10 kHz. Our production range includes single-pole insulated voltage transformers for connection between conductors and earth, and dual-pole insulated voltage transformers for connection between conductor and conductor.
VTS - Current transformers/voltage transformers for medium voltage
Medium-voltage current transformers for indoor applications that transfer one or more network-side primary currents proportionally and true to phase into standardised secondary currents. These are isolated in cast resin and, alongside their primary function as current transformers, also act as busbar supports. These current transformers can be used both for measuring and protection purposes.
The medium-voltage current transformers are also available as multi-core transformers. The maximum possible number of cores depends on the output selected and the accuracy class, which specify the core volume. The current transformers are optionally available with primary or secondary switching.
The current transformers with primary switching offer the option of choosing between two primary nominal currents, depending on the connection of the primary connections through parallel or serial circuits. The primary-side nominal currents can be achieved only in a ratio of 1:2. For current transformers having secondary switching, the switching is made possible by one or more pickups. As a result, the primary-side nominal currents can also be achieved in various ratios.
EMS- Energy management
The energy management software “econ 3.0” is one of the currently leading solutions.
Intuitive operation, fast learning curves and short-term success in use underline our position.
The modular, flexible structure enables adaptation to the individual framework conditions on site. Regardless of the data source, the data points can be easily and quickly integrated into any hierarchy structure, as well as combined into different key figures.
The graphic preparation in the form of user-specific dashboards delivers immediate results. After all, a picture says more than 1,000 words.
COUNTER- Energy meters
The 1-phase and 3-phase energy meters M1Pro and M3Pro Professional set new standards in the field of DIN rail energy meters.
The energy meters are available with S0 output, M-Bus, Modbus, KNX and LAN -TCP/IP interface as energy transformer meter as well as for direct measurement with the interfaces S0 output, M-Bus and Modbus.
The devices are ideally suited for energy and power measurement, demand and load analysis, energy controlling, cost center management as well as billing applications and energy management according to ISO 50001.
FAQs
What are the key features of the current transformers for industry offered by MBS AG?
MBS AG provides a cutting-edge series of current transformers, known as the CTB series, designed specifically for industrial applications. These transformers offer precision and reliability, ensuring accurate measurement and monitoring of electrical currents within industrial settings. The CTB series is equipped to meet the demands of diverse industrial environments, making it a preferred choice for many businesses.
How do the current transformers for tariffs by MBS AG stand out in the market?
The current transformers for tariffs by MBS AG are engineered to streamline tariff monitoring and management processes. These transformers are tailored to meet the requirements of tariff measurements, providing efficient and accurate data for billing and analysis purposes. With a focus on compliance and performance, MBS AG's current transformers for tariffs offer a comprehensive solution for businesses seeking reliable tariff management systems.
What can be expected from the medium-voltage transformers in MBS AG's product range?
MBS AG's medium-voltage transformers are designed to deliver robust performance in demanding applications. These transformers are built to withstand high voltage levels while ensuring efficient power distribution and management. With a reputation for quality and durability, MBS AG's medium-voltage transformers are trusted by industries requiring reliable power solutions for their operations.
